*Low fuel consumption
*Low noise: Well-designed gear transmission structure, can greatly reduce vibration and noise!
*Easy start: perforated injection, equipped with geared motor, easy and reliable start!
*Strong power: using overhead backlash oil pump and low inertia injection technology
*Long service life:1000hours durability test
*High strength crankcase/crankshaft/connecting rod design
*Compact structure design
*CE
Parameter
Model | MLD170F | MLD173F | MLD178F |
Bore*Stroke(mm) | 70*55 | 73*59 | 78*62 |
Displacement(cc) | 211 | 247 | 296 |
Engine Speed(rpm) | 3000/3600 | 3000/3600 | 3000/3600 |
Rated AC Output (hp) | 3.4/3.8 | 3.9/4.3 | 5/5.4 |
Max. AC Output (hp) | 3.8/4.2 | 4.3/4.7 | 5.5/6 |
Fuel Tank Capacity(L) | 2.5 | 2.5 | 3.5 |
Lube Oil Capacity(L) | 0.75 | 0.75 | 1.1 |
Fuel comsumption(g/kw.h) | 280 | 280 | 290 |
N.W./G.W.(kg) | 26/29 | 27 / 30 | 32/35 |
Packing Size(L×W×H) | 430*385*460 | 430*385*460 | 478*460*521 |
