*Powered by powerful commercial diesel engine
*Simple in structure,Reliable in performance
*Minimal vibration&smooth running
*High quality ceramic mechanical seal
*Adding an oil-water separator to the fuel supply system to help start-up easily
*CE
Parameter
Model | MLD50H | MLD80H |
Diesel HIGH LIFT water pumps | Diesel HIGH LIFT water pumps | |
Inlet diameter | 2inch | 3inch |
Outlet diameter | 2inch/1.5inch/1.5inch | 3inch/1.5inch/1.5inch |
Max. capacity | 23m³/hr | 40m³/hr |
Max discharge head | 80mm | 80m |
Engine | MLD178F/296cc | MLD186FA, /418cc |
Engine speed | 3600 rpm | 3600 rpm |
Self-priming time | 180s/7m | 180s/7m |
Max. suction head | 7m | 7 m |
Fuel tank | 3.5 L | 5.5L |
Start mode | Recoil / Electric start | Recoil / Electric start |
N.W./G.W.(kg) | 42/44 | 75/78 |
Packing Size(L×W×H) | 575*475*590 | 670*510*630 |
