ML-1350D-T: specification reconciliation before purchase
The specification status below distinguishes current MLBE product-listing statements from configuration-specific evidence that still needs factory confirmation.
| Item | Published detail | Verification status |
|---|---|---|
| Model identification | Page name: ML-1350D-T; current technical table: ML1350DE-T | Not confirmed as the same version |
| Engine and output | Listing refers to MLD186FA / 418 cc, with 10 HP and 6.3 kW output figures | Confirm rating basis, speed and exact engine nameplate |
| Tilling envelope | 800–1,350 mm width and greater than 300 mm depth appear in the table | Do not apply to ML-1350D-T until the table’s model identity is resolved |
| Transmission | A #32 gearbox and multiple travel gears are referenced | Obtain the matching ratio and gearbox drawing |
Model-specific selection note
The model name in the technical table differs from this page’s title. Published power values may reflect different test definitions; do not treat them as directly comparable without a rating standard, engine speed and configuration. This is a data-quality hold, not a confirmed specification correction.
Compare the ML1350DE-T turning-system model and the related operation and buying guide. Consult the MLBE model manual library; request matching technical drawings, maintenance instructions, relevant spare-parts references and evidence of tests through technical support. For wholesale specifications and quantities, email the factory.
Identifying an ML-1350D-T order correctly
Use the complete ML-1350D-T identifier when requesting the supplied configuration, attachment details and parts information. Similar MLBE tiller names can refer to different versions. Keep the agreed blade, wheel and starting arrangements together in the order record.
Configuration checklist
- Describe soil condition, crop or row spacing, working width and the intended cultivation task.
- Identify the blade set, transport wheels, depth-control arrangement and the connector for each proposed implement.
- Separate standard equipment from optional attachments and confirm the assembled operating and transport dimensions.
How should a dealer handle similar model names?
Record the complete designation and production identification, with photographs where available. Compare the relevant drawing or specification before sharing service parts or application claims between models.
Operation and service planning
Inspect the working area for stones, wire and other obstructions. Avoid cultivation when soil is too wet to work without smearing or compaction. Select the approved depth and gear for the conditions. Stop and isolate the machine, and wait for all movement to cease before clearing or changing attachments.
For the applicable operating instructions or parts reference, send the complete model and production identification to MLBE technical support. The MLBE document centre helps identify the relevant resources. Confirm document revision, included accessories, packaging and agreed support terms for the supplied configuration.
Compare ML1350DE and ML1350DE-T for related MLBE options. For factory orders, provide quantities, destination, configuration and artwork requirements through MLBE dealer and OEM supply.
ML-1350D-T: identification before ordering
Which model designation should the quotation use?
The title uses ML-1350D-T while the table identifies ML1350DE-T. Ask MLBE to confirm the exact model, engine and starting system in a single configuration sheet before relying on the listed dimensions or performance figures. The published 10HP and 6.3 kW power values are not equivalent; confirm the engine rating for the selected configuration.
Explore the diesel power tiller range and MLBE power tiller selection guide. For configuration-specific documents, contact MLBE technical support.
Parameter
| Model | ML1350DE-T |
| Dimensions(mm) | 1600×1050×1100 |
| Tilling Width(mm) | 800-1350 |
| Tilling Depth(mm) | >300 |
| Shifting Gears | 1, 0 ( -1 ), 2, 3 |
| Transmission Mode | #32Gear box |
| Engine Model | Diesel MLD186FA |
| Displacement(cc) | 418 |
| Max Output(Hp.kw/rpm) | Confirm engine output, units and rated speed |
| Starting System | Recoil Start/Electric start |
| Transporting Wheels | 4.00-8 |
| Tilling Blades | 4+1 group 40pcs |
| Packing Dimensions(mm) | 1050×570×780 |
| N.W/G.W(Kg) | 132 / 142 |
| Cont. Load (20 GP) | 65 |
| Cont. Load (40 HQ) | 132 |
