ML6000(E)–ML10000(E): configuration checks
Does the ML10000(E) model name mean 10 kW continuous output?
No. Use the rated-output row for the selected electrical configuration, rather than the model name or maximum-output figure. Request a confirmed data sheet showing voltage, frequency and rated output.
Which starting system should I order?
The published table lists recoil starting, while model names include an (E) suffix. Ask MLBE to confirm the actual starting system and whether a battery is included before placing the order.
For order preparation, see the generator kW and kVA guide. Browse the petrol generator range, or request model-specific documents through MLBE technical support.
Parameter
| Model | ML6000(E) | ML7000(E) | ML9000(E) | ML10000(E) |
| Generator | ||||
| Frequency(Hz) | 50/60 | 50/60 | 50/60 | 50/60 |
| Rated Voltage(V) | 220V/110V | 220V/110V | 220V/110V | 220V/110V |
| Rated Output(Kw) | 5.0/5.5 | 6.0/6.5 | 7.5/8.0 | 8.0/9.0 |
| Max Output(Kw) | 5.5/6.0 | 6.5/7.0 | 8.0/9.0 | 8.5/10 |
| Fuel Tank Capacity(L) | 25 | 25 | 25 | 30 |
| Running Time@50%Loading(H) | 12 | 10 | 8.5 | 8.5 |
| Engine | ||||
| Engine model | ML188F(E) | ML190F(E) | ML192F(E) | ML192F(E) |
| Displacement(CC) | 389 | 420 | 456 | 456 |
| Starting system | Recoil Start | Recoil Start | Recoil Start | Recoil Start |
| Packing Details | ||||
| N.W/G.W(Kg) | 83/89 | 88/94 | 98/104 | 102/108 |
| Dimension(L×W×H MM) | 705x570x585 | 720x570x580 | 705x570x585 | 705x570x585 |
