MLD2200H, MLD4000H and MLD5000H: choosing a model
How do I compare the three output options?
Compare each model’s rated output with the intended running load and starting requirements. The table separates rated and maximum output; specify both model and frequency when requesting a quotation.
Are all listed voltage options supplied on one unit?
Ask MLBE to confirm the selected voltage, phase, frequency and socket arrangement. The list of voltage options should not be treated as confirmation that every configuration is available on the same unit.
For order preparation, see the generator supplier checklist. Browse the diesel generator range, or request model-specific documents through MLBE technical support.
Parameter
| Model | MLD2200H | MLD4000H | MLD5000H |
| Voltage(V) | 120,220,230,120/240,220/380 | ||
| Frequency(Hz) | 50/60 | ||
| Max AC Output(kw) | 1.9/2.2 | 3.3/3.6 | 4.6/5.0 |
| Rated AC Output(kw) | 1.7/2.0 | 3.0/3.3 | 4.2/4.6 |
| Power Factor | 1 | 1 | 1 |
| DC output | 12V/8.3A | 12V/8.3A | 12V/8.3A |
| Phase | Single phase | Single phase | Single phase |
| Panel Detail | EU tyep socket, Circuit Breaker, Low Oil Alert Warn | ||
| Engine | MLD170F/211cc | MLD178F/296cc | MLD186FA/418cc |
| Alternator | 100% Copper Wire, Brush Motor, with AVR | ||
| Fuel Tank Capacity | 12.5L | 12.5L | 12.5L |
| N.W./G.W.(kg) | 60/65 | 65/68 | 81/86 |
| Packing Size(L×W×H) | 670*480*550 | 670*480*550 | 670*480*550 |
