MLD6500B–MLD12500B: quotation requirements
Which electrical details need confirmation for the B series?
Voltage, frequency, panel and alternator fields are blank in the published table. Request a completed data sheet for the selected B-series model before comparing quotations or placing an order.
What should I compare between B-series models?
Review the rated-output row, engine model, packed weight and dimensions for the exact unit. Ask MLBE to identify the electrical configuration associated with each paired output figure.
For order preparation, see the generator supplier checklist. Browse the diesel generator range, or request model-specific documents through MLBE technical support.
Parameter
| Model | MLD6500B | MLD7500B | MLD10000B | MLD11500B | MLD12500B |
| Voltage(V) | |||||
| Frequency(Hz) | |||||
| Max AC Output(kw) | 5.5/6.0 | 6.5/7.0 | 7.3/7.8 | 8.0/8.5 | 10.0/11.0 |
| Rated AC Output(kw) | 5.0/5.5 | 6/6.5 | 6.8/7.3 | 7.5/8.0 | 9.2/10.0 |
| Power Factor | 1 | 1 | 1 | 1 | 1 |
| DC output | 12V/8.3A | 12V/8.3A | 12V/8.3A | 12V/8.3A | 12V/8.3A |
| Phase | Single phase | Single phase | Single phase | Single phase | Single phase |
| Panel Detail | |||||
| Engine | MLD186FA, /418cc | MLD188F, /477cc | MLD192FA, /498cc | MLD195FAE/532cc | MLD1100FE/667cc |
| Alternator | |||||
| Fuel Tank Capacity | 22 L | 22 L | 22 L | 22 L | 22 L |
| N.W./G.W.(kg) | 116/120 | 116/120 | 122/125 | 123/126 | 142/145 |
| Packing Size(L×W×H) | 768*428*655 | 768*428*655 | 768*428*655 | 768*428*655 | 825*615*865 |
