MLDW200A: welding and auxiliary-power enquiries
What welding details should I confirm before ordering?
The table lists an operating-current range of 20–200 A. Ask for the supported electrode sizes, welding duty cycle and a confirmed welding specification for the intended job.
Can welding and AC output be used together?
Confirm the permitted simultaneous loads with MLBE. Do not assume the full listed AC rating remains available while welding; request the operating limits for the exact configuration.
For order preparation, see the generator supplier checklist. Browse the diesel generator range, or request model-specific documents through MLBE technical support.
Parameter
| Model | MLDW200A(E) |
| Model | LQ11500-CE |
| Voltage(V) | 220/380 |
| Frequency(Hz) | 50 |
| Max AC Output(kw) | 7.2 |
| Rated AC Output(kw) | 6.5 |
| Starting system | Electric start with battery |
| 4 wheels | with |
| Panel Detail | EU tyep socket, Circuit Breaker, Low Oil Alert Warn, digital display |
| No load voltage（V) | 220/380 |
| Operating welding voltage(V) | 220/380 |
| Operating current（A) | 20-200 |
| Max.Arcing current(A) | 200 |
| Engine | MLD195FA |
| Alternator | 100%copper wire |
| Fuel Tank Capacity | 18L |
| N.W./G.W.(kg) | 136/142 |
| Packing Size(L×W×H) | 768*428*655 |
