MLD168F: equipment integration
What must match when fitting an MLD168F diesel engine?
Confirm the output-shaft diameter, length, keyway, rotation direction and mounting-hole pattern against the driven equipment. Include the required operating speed and load when requesting a drawing and configuration-specific quotation.
Explore the diesel engine range and diesel maintenance guide. For configuration-specific documents, contact MLBE technical support.
MLBE MLD168F 196cc Diesel Engine
The MLBE MLD168F is a compact diesel engine designed for generators, water pumps and small agricultural equipment. Its 196 cc displacement and compact dimensions make it suitable for equipment manufacturers, importers and distributors requiring a small diesel power unit.
Compare Diesel Engine Configurations
For other engine sizes, review the MLD170F / MLD173F / MLD178F series. Confirm shaft dimensions, mounting and rated output for the driven equipment before selecting an alternative.
Technical Specifications
| Model | MLD168F |
|---|---|
| Bore × stroke | 68 × 54 mm |
| Displacement | 196 cc |
| Engine speed | 3000 / 3600 rpm |
| Rated output | 2.6 / 3.0 HP |
| Maximum output | 3.0 / 3.4 HP |
| Fuel tank capacity | 3 L |
| Engine oil capacity | 0.7 L |
| Fuel consumption | 250 g/kWh |
| Net / gross weight | 20 / 22 kg |
| Packing dimensions | 395 × 305 × 361 mm |
For Importers and Equipment Manufacturers
Before ordering, confirm the required shaft configuration, engine speed, starting system, application, packaging and spare-parts requirements. The engine should be matched to the equipment load and intended duty cycle.
