ML168F / ML170F / ML170FB: model selection
How should I compare the three petrol engines?
The table separates displacement, net power and torque by model. Match the required operating point and shaft interface to the driven equipment; ask MLBE to confirm the exact starting system and model-specific documentation.
Explore the gasoline engine range and petrol engine troubleshooting guide. For configuration-specific documents, contact MLBE technical support.
MLBE ML168F / ML170F / ML170FB Gasoline Engines
The MLBE ML168F, ML170F and ML170FB are compact four-stroke gasoline engines designed for generators, water pumps, power tillers and other small machinery. The range provides several displacement and output options while retaining a common platform suitable for distributors and original equipment manufacturers.
Key Features
- Four-stroke, single-cylinder gasoline engine design
- Recoil-start configuration with electric-start options where specified
- Anti-vibration design to support smoother operation
- Suitable for generators, pumps, tillers and compact machinery
- Designed for regular agricultural and light industrial use
Technical Specifications
| Specification | ML168F | ML170F | ML170FB |
|---|---|---|---|
| Displacement | 196 cc | 212 cc | 223 cc |
| Net power | 4.1 kW at 3600 rpm | 4.4 kW at 3600 rpm | 5.0 kW at 3600 rpm |
| Net torque | 11 N·m at 2500 rpm | 12 N·m at 2500 rpm | 13 N·m at 2500 rpm |
| Fuel tank capacity | 3.6 L | 3.6 L | 3.6 L |
| Engine oil capacity | 0.55 L | 0.55 L | 0.55 L |
For Importers and Equipment Manufacturers
Buyers should confirm the required shaft configuration, starting system, application, packaging and any market-specific compliance documentation before ordering. Model selection should be based on the required output, duty cycle and equipment interface.
