MLBE MLD170F / MLD173F / MLD178F Diesel Engines

*Low fuel consumption

*Low noise: Well-designed gear transmission structure, can greatly reduce vibration and noise!

*Easy start: perforated injection, equipped with geared motor, easy and reliable start!

*Strong power: using overhead backlash oil pump and low inertia injection technology

*Long service life:1000hours durability test

*High strength crankcase/crankshaft/connecting rod design

*Compact structure design

*CE

Categories: ,

Parameter

Model MLD170F MLD173F MLD178F
Bore*Stroke(mm) 70*55 73*59 78*62
Displacement(cc) 211 247 296
Engine Speed(rpm) 3000/3600 3000/3600 3000/3600
Rated AC Output (hp) 3.4/3.8 3.9/4.3 5/5.4
Max. AC Output (hp) 3.8/4.2 4.3/4.7 5.5/6
Fuel Tank Capacity(L) 2.5 2.5 3.5
Lube Oil Capacity(L) 0.75 0.75 1.1
Fuel comsumption(g/kw.h) 280 280 290
N.W./G.W.(kg) 26/29 27 / 30 32/35
Packing Size(L×W×H) 430*385*460 430*385*460 478*460*521
