MLD170F / MLD173F / MLD178F: replacement enquiries
Can these three diesel engines be treated as interchangeable?
A shared model family does not establish mechanical compatibility. Request the mounting and shaft drawings for the selected engine, then confirm the coupling, operating speed, starting system and available installation space.
Explore the diesel engine range and diesel maintenance guide. For configuration-specific documents, contact MLBE technical support.
Parameter
| Model | MLD170F | MLD173F | MLD178F |
| Bore*Stroke(mm) | 70*55 | 73*59 | 78*62 |
| Displacement(cc) | 211 | 247 | 296 |
| Engine Speed(rpm) | 3000/3600 | 3000/3600 | 3000/3600 |
| Rated AC Output (hp) | 3.4/3.8 | 3.9/4.3 | 5/5.4 |
| Max. AC Output (hp) | 3.8/4.2 | 4.3/4.7 | 5.5/6 |
| Fuel Tank Capacity(L) | 2.5 | 2.5 | 3.5 |
| Lube Oil Capacity(L) | 0.75 | 0.75 | 1.1 |
| Fuel comsumption(g/kw.h) | 280 | 280 | 290 |
| N.W./G.W.(kg) | 26/29 | 27 / 30 | 32/35 |
| Packing Size(L×W×H) | 430*385*460 | 430*385*460 | 478*460*521 |
