Name: MLBE MLD50-S / MLD80-S Diesel Water Pumps
Brand: MLBE

MLBE MLD50-S / MLD80-S Diesel Water Pumps

MLBE MLD50-S / MLD80-S Diesel Water Pumps

2-inch and 3-inch diesel cleaning-water-pump options for irrigation and general transfer
Maximum capacities of 22m³/h and 40m³/h with 28m maximum discharge head
Two outlet sizes let dealers cover common farm-water-transfer jobs with a compact two-model range
Suitable for buyers comparing required flow, hose diameter, suction conditions and start configuration before purchase

MLD50-S / MLD80-S: choosing the connection size

How do I choose between the two S-series pumps?

The table lists 2-inch connections for MLD50-S and 3-inch connections for MLD80-S. Provide the required flow, elevation difference, hose length and water condition so MLBE can confirm a suitable operating point and hose package.

Explore the diesel water pump range and agricultural water pump selection guide. For configuration-specific documents, contact MLBE technical support.

Parameter

Model	MLD50-S	MLD80-S
	Diesel Cleaning pumps	Diesel Cleaning pumps
Inlet diameter	2inch	3inch
Outlet diameter	2inch	3inch
Max. capacity	22m³/hr	40 m³/hr
Max discharge head	28m	28m
Engine	MLD168F/196cc	MLD168F/196cc
Engine speed	3600 rpm	3600 rpm
Self-priming time	180s/7m	180s/7m
Max. suction head	7 m	7 m
Fuel tank	3L	3L
Start mode	Recoil / Electric start	Recoil / Electric start
N.W./G.W.(kg)	30/32	32/34
Packing Size(L×W×H)	555430445	555430445
