MLD150: planning a 6-inch pump installation
What information is needed for an MLD150 quotation?
The published table identifies 6-inch inlet and outlet connections and electric starting. Send the intended flow, elevation change, hose route and water condition, and ask whether the battery, hoses, connectors and strainer are included.
Explore the diesel water pump range and agricultural water pump selection guide. For configuration-specific documents, contact MLBE technical support.
Parameter
| Model | MLD150 |
| Diesel Cleaning pumps | |
| Inlet diameter | 6inch |
| Outlet diameter | 6inch |
| Max. capacity | 150m³/hr |
| Max discharge head | 15m |
| Engine | MLD192FA, /498cc |
| Engine speed | 3600 rpm |
| Self-priming time | 180s/7m |
| Max. suction head | 7m |
| Fuel tank | 12.5L |
| Start mode | Electric start |
| N.W./G.W.(kg) | 98/102 |
| Packing Size(L×W×H) | 810*600*860 |
