Name: MLBE MLD80T / MLD100T Diesel Water Pumps
Brand: MLBE

MLBE MLD80T / MLD100T Diesel Water Pumps

MLBE MLD80T / MLD100T Diesel Water Pumps

3-inch and 4-inch diesel trash-water-pump options for drainage and agricultural transfer
Maximum capacities of 40m³/h and 65m³/h respectively
Trash-pump positioning helps dealers separate dirty-water and drainage enquiries from standard irrigation pump demand
Model selection should consider solids tolerance requirements, flow, discharge head and hose size for the intended job

MLD80T / MLD100T: water-condition checks

What should I tell MLBE before ordering a trash pump?

Describe the water source and expected solids, including their approximate size and concentration. Request the maximum permitted solids size and strainer specification for the exact model; the trash-pump description alone does not define those limits.

Explore the diesel water pump range and water pump types guide. For configuration-specific documents, contact MLBE technical support.

Parameter

Model	MLD80T	MLD100T
	Diesel trash water pumps	Diesel trash water pumps
Inlet diameter	3 inch	4inch
Outlet diameter	3 inch	4inch
Max. capacity	40m³/HR	65 m³/hr
Max discharge head	22m	18m
Engine	MLD178F/296cc	MLD186FA, /418cc
Engine speed	3600 rpm	3600 rpm
Self-priming time	180s/7m	180s/7m
Max. suction head	7m	7m
Fuel tank	3.5L	5.5L
Start mode	Recoil / Electric start	Recoil / Electric start
N.W./G.W.(kg)	47/49	80/83
Packing Size(L×W×H)	575475590	670510630
