Parameter
| Model | MLWP40 |
| Pump Type | Centrifugal Pump |
| Inlet/outlet size | 1.5”(40mm) |
| Max Lift(M) | 15 |
| Max discharge capacity (M³/h) | 14 |
| Suction(M) | 6 |
| Engine model | ML154F |
| Engine Displacement (CC) | 100 |
| Rated Power(Kw/Rpm) | 1.3/3600 |
| Starting system | Recoil Start |
| Fuel tank capacity (L) | 1.4 |
| N.W(Kg) | 11.5 |
| Dimension(L×W×H MM) | 335*300*380 |
For pump selection advice, read the MLBE agricultural water pump buying guide and the water pump type comparison. For servicing, see the gasoline water pump troubleshooting guide.
MLWP40 FAQ
What size pump is the MLWP40?
It is a 1.5-inch (40 mm) centrifugal gasoline water pump.
What are the maximum lift and flow figures?
The page specifies a maximum lift of 15 m and a maximum discharge capacity of 14 m³/h.
Which engine does it use?
The MLWP40 uses the ML154F 100cc gasoline engine rated at 1.3 kW at 3600 rpm.
What is the specified suction capability?
The specification table lists a suction height of 6 m. Actual performance depends on installation, hose losses and operating conditions.
Related Water Pumps
- MLWP50 / MLWP80 Gasoline Water Pumps — larger general-purpose options for higher flow and larger hose sizes.
- MLWP50H / MLWP80H High-Lift Gasoline Water Pumps — suitable when delivery head is a more important selection factor.
Request Pump Selection Support
Contact MLBE with the required flow, vertical lift, suction height, hose length, water condition and order quantity. This helps match the pump to the actual irrigation or transfer duty rather than selecting by outlet size alone.
